Gulfstream 2 Whites
The Gulfstream 2 is a durable IK10, high-output in-grade linear fixture for wall grazing, asymmetric wall wash, and façade lighting. Its precision optics and impact-resistant design make it ideal for building exteriors, pathways, plazas, and landscapes, delivering bold, uniform illumination.
Description
Outdoor buriable IP68, very high output luminaire with glare control and secondary lenses for asymmetric throw. Gulfstream 2® is available with trim or as a trimless model with a seamless tempered glass edge, exposing only a thin border of the inground mounting housing.
Stand alone or continuous housings with covers between fixtures which simplify installation by providing a thru-wiring option.
Options include internal louvers for glare control and non-slip lens treatments. Gulfstream 2® is also available with white LEDs and the option of line voltage options.
Resources
Quick Specs
Title | Gulfstream 2 Whites |
|---|---|
Certifications | RoHS, UL Listed, CE |
CRI | 80+ (white) |
Warranty | 5 yr/ 50,000 hour limited warranty |
Environment | IP68/IK10 |
Max Run | 120-277V Integral - LS 13.5w/ft 600lm/ft, LH 19w/ft 1205lm/ft |
LED Wattage | 120V-277V 19w/ft 1180lm/ft |
Electrical | Integral 120-277V |
Finish | Anodized dark gray / Liquid painted for black |
Mounting | Ingrade Aluminum Installation Profile |
Optics | Optics : 10° , 20° , 40° , 10° x 60° , 20° x 40° , Asymmetric, Wide |
Dimming | DMX with RDM / DMX/ DALI / 0-10(1-10V) / PWM DIMMING |
CCT | 2700K / 3000K / 4000K / 5000K / 6500K |
Length (nom.) | 1', 2', 3', 4' |
Construction | Extruded aluminum / Tempered glass lens |
