3650 Leaf

Leaf wall mounted series is designed for outstanding indirect lighting from two matching low profile curved designed; 10 inches and 18 inches wide.

Description

The Leaf wall mounting series is designed for outstanding direct or indirect lighting from two matching low profile curved slim designs, 14 and 22 inches long.


Leaf uses high performance LEDs with foward throw optic for superior distribution and evenness. Providing energy efficiency, long life and consistent color.

Resources

Quick Specs

Title
Leaf 3650
Certifications
UL Listed, DLC Premium Certified
CRI
80+
Warranty
5 yr/ 50,000 hour limited warranty
Environment
IP66 - Suitable for Wet Locations. Natatorium - Marine Grade Finish Operating Temperature: -40 ̊F to 122 ̊F
Max Run
N/A
LED Wattage
25W, 50W, 75W, 100W, 150W, 160W, 190W, 240W, 320W
Electrical
120-277V AC / 277-480V AC Input line voltage
Finish
Epoxy Powder Coated White, Bronze, Custom
Mounting
Flush Mount, Yoke Mount, 4" Swivel Mount, Extended Arm, Pendant Mount (Single, Double).
Optics
Standard Forward Throw or Optional Wide Forward Throw Rotatable Lenses (Every 90 ̊)
Dimming
Non-Dimming, 0-10V Dimming
CCT
3000K, 3500K, 4000K, 5000K
Length (nom.)
14", 22"
Construction
Durable Die-Cast Aluminum Housing. Stainless Steel Hardware. High impact protective lens.
